Omnitronic MAXX-1000DSP MK2 2.1 Active System

Mobile 2.1 system with DSP and 1000 watts RMS power. Provides perfect sound and good level stability in various kinds of mobile PA applications up to medium-sized party events - ideal for solo entertainers, bands and mobile discos. 38 cm subwoofer (15) in bassreflex cabinet provides powerful, dry bass. Two satellites with 20 cm bass-midrange speakers (8) and 3.5 cm driver system (1.4). Satellites with passive 2-way crossover, PTC tweeter protection. Balanced signal input XLR/6.3 mm jack L/R, with level switch. Additional stereo RCA input. Parallel XLR line output L/R. 5 EQ presets with indicators, DSP-controlled. Signal limiter, DSP-controlled. Separate volume control for subwoofer and satellites. Adjustable crossover frequency 80-200 ,Hz. Stereo/mono selection. Subwoofer with plywood enclosure. Satellites with MDF enclosure. Enclosure (15 mm) with scratch-resistant lacquer surface, steel grille and flange. Subwoofer with M20 metal flange for mounting a satellite speaker. 4 castors, 2 of which with locking brakes. Delivery includes two speaker cables.

Technické parametry

Power supply	230 V AC, 50 Hz
Power consumption	280 W (1/8 power)
Amplifier power	LF 600 W RMS + HF 2 x 200 W RMS
Components Subwoofer	38 cm woofer (15,)
Components Satellite speakers	20 cm woofer (8), 3.6 cm driver (1.4)
Frequency range Subwoofer	45-150 Hz
Frequency range Satellite speakers	80-19000 Hz
Sensitivity Subwoofer	97 dB (1 W, 1 m)
Sensitivity Satellite	95 dB (1 W, 1 m)
Maximum SPL Subwoofer	127 dB (1 m)
Maximum SPL Satellite	121 dB (1 m)
Dispersion angle (HxV)	50-100 x 55
Connection
Line input	combination XLR/6.3 mm jack L/R
Parallel output	XLR L/R
Satellite	Speaker L/R
Dimensions (L x W x H) Subwoofer	700 x 476 x 530 mm
Dimensions (L x W x H) Satellite	240 x 266 x 415 mm
Weight Subwoofer	35 kg
Weight Satellite	10 kg (piece)
